Safety Solution

Active Hood Lift System

Sensor & Controller This pedestrian protection system detects collisions with pedestrians through sensors embedded within the bumper. It then raises the hood to create a cushioning space, effectively reducing head injury risk for pedestrians.

Features

01 Integrated sensor + ECU

02 Simultaneous detection of impact intensity and location

03 Robust pedestrian identification algorithm

Specification

Operating Voltage	Operating Current	Operating Temperature
9V ~ 16V	Max 200mA	-30℃ ~ 95℃

System Environment	IP Grade	Weight
AutoSAR / OTA	IP67	Max 420g

Safety Solution

Active Hood Lift System

Hinge Actuator The hinge actuator detects pedestrian impacts through sensors, elevating the hood hinge (on the rear hood) to create space between the hood and engine compartment. This cushioning effect is designed to reduce head injuries for pedestrians in the event of a collision.

Features

01 Fast response time with rear hood deployment

02 Lightweight and compact design

03 Customizable stroke options tailored to customer needs

Specification

Operating Current	Operating Temperature	Operating Time
DC 1.2A	-30℃ ~ 95℃	Under 3ms

IP Grade	Weight	Stroke
IP67	Max 300g	Max 150mm

Safety Solution

Active Hood Lift System

Latch Actuator The latch actuator detects pedestrian impacts through sensors, elevating the hood latch (on the front hood) to create space between the hood and engine compartment. This cushioning effect is designed to reduce head injuries for pedestrians in the event of a collision.

Features

01 Fast response time with front hood deployment

02 Lightweight and compact design

03 Customizable stroke options tailored to customer needs

Specification

Operating Current	Operating Temperature	Operating Time
DC 1.2A	-30℃ ~ 95℃	Under 3ms

IP Grade	Weight	Stroke
IP67	Max 180g	Max 85mm

Safety Solution

Anti-Pinch Sensors

Anti-Pinch Sensor(TYPE 10) A contact sensor designed to detect objects or fingers caught during the operation of a power tailgate or power sliding door, preventing damage and injury.

Features

01 Compact, lightweight, and cost-effective contact sensors

02 Suitable for various applications(Automotive, Robotics, Industrial)

03 Customizable to meet specific customer requirements

Specification

Operating Voltage	Operating Current	Operating Temperature
Max 24V DC	Max 10㎃	-40℃~80℃

Actuating Forc(Test rod Ø4 mm)	Contact Transition Resistance	Applied Resistance
< 35N	< 500Ω	3㏀

Safety Solution

Anti-Pinch Sensors

Anti-Pinch Sensor(TYPE 11) A contact sensor designed to detect objects or fingers caught during the operation of a power tailgate or power sliding door, preventing damage and injury.

Features

01 Compact, lightweight, and cost-effective contact sensors

02 Suitable for various applications (Automotive, Robotics, Industrial)

03 Customizable to meet specific customer requirements

Specification

Operating Voltage	Operating Current	Operating Temperature
Max 24V DC	Max 10㎃	-40℃~80℃

Actuating Force(Test rod Ø4 mm)	Contact Transition Resistance	Applied Resistance
< 35N	< 500Ω	3㏀/20㏀/without Resistor

Safety Solution

Anti-Pinch Sensors

Anti-Pinch Sensor(TYPE 20) A contact sensor designed to detect objects or fingers caught during the operation of a power tailgate or power sliding door, preventing damage and injury.

Features

01 Compact, lightweight, and cost-effective contact sensors

02 Suitable for various applications(Automotive, Robotics, Industrial)

03 Customizable to meet specific customer requirements

Specification

Operating Voltage	Operating Current	Operating Temperature
Max 24V DC	Max 10㎃	-40℃~80℃

Actuating Force(Test rod Ø4 mm)	Contact Transition Resistance	Applied Resistance
< 35N	< 500Ω	6.2㏀
